Standardized cabinets achieve partition safety isolation of the energy storage system, paired with active safety monitoring and early warning design, as well as Pack-level immersion fire technology to ensure system safety and control.
Adopt efficient thermal management design and hierarchical linkage protection to guarantee the safe and stable operation of products.
Feature an highly integrated design with decentralized deployment and centralized scheduling.
Boast a compact structure with a small footprint, enabling easy installation, operation, and maintenance.
Equipped with an IP54 protection grade, offering stronger environmental adaptability.
Standardized design reduces operation and maintenance costs, while standardized production ensures rapid delivery and lowers overall life cycle costs.
High-efficiency balancing BMS: single-group string design + high-efficiency balancing technology.
High-performance optical storage all-in-one: simultaneously supports loads, batteries, the power grid, diesel generators, and photovoltaic systems.
All-in-one multi-capability: energy storage mode, off-grid uninterrupted power supply, dynamic capacity expansion, peak cutting, and valley filling optimization power mode.
The energy storage system is factory-prefabricated to reduce on-site installation costs.
Maximize the utilization of green energy and save electricity expenses.
| Model | EnerCube-250KW516KWh-M | |
| Battery Parameter | ||
| Cell type | LFP 280Ah | |
| Battery Pack configuration | 14.336KWh/1P16S | |
| Battery system configuration | (200KWh/1P224S) *3 | |
| Battery voltage range | 627~806V | |
| Temperature measurement quantity | 84*3 | |
| Charging/discharge ratio | ≤0.5C | |
| The depth of discharge | 90%DOD | |
| Cycles | >8000 | |
| Maximum battery system efficiency | ≥96% | |
| AC Parameter | ||
| Rated AC power | 250KW | |
| Maximum AC power | 275KW | |
| Rated voltage | 400V (-20%~+15%) | |
| Rated current | 360A | |
| Rated frequency | 50/60Hz | |
| DC current component | <0.5%Ipn | |
| AC current distortion rate | <3% | |
| Power factor | -1~+1 | |
| Overload capacity | 110% long term | |
| Alternating current system | Three-phase four-wire + ground wire (3W+N+PE) | |
| Isolation transformer | Yes | |
| Common Parameter | Battery outdoor cabinet | PCS outdoor cabinet |
| Protection class | IP55 | IP54 |
| Fire protection system | Perfluorohexone + aerosol | -- |
| Operating temperature range | -30℃ to 55℃ | -30℃ to 55℃ |
| Cooling mode | Air conditioning cooling | Intelligent air cooling |
| Size WDH (mm) | (1200 * 1100 * 2350) *3 | 1500 * 1100 * 2350 |
| Weight (kg) | 2400*3 | 2000 |
| Communication mode | CAN, RS485 | RS485, TCP/IP |
| Display | Touch LCD display | Touch LCD display |
| Relative humidity | 5~95%RH, no condensation | 5~95%RH, no condensation |
| Highest altitude | 4500m (> 3000 Derating required) | 4500m (> 3000 Derating required) |
| Noise | <70dB | <70dB |
