Standardized cabinets realize partition safety isolation of energy storage system, active safety monitoring and early warning design, and Pack-level immersion fire technology to ensure the safety and control of the system.
Efficient thermal management design, hierarchical linkage protection, to ensure the safe and stable operation of products.
Integrated design, highly integrated; Decentralized deployment and centralized scheduling.
Compact structure, small footprint, easy to install, operation and maintenance.
IP54 protection grade, stronger environmental adaptability.
Standardized design reduces operation and maintenance costs, standardized production achieves rapid delivery, and reduces overall life cycle costs.
High-efficiency balancing BMS: single-group string design + high-efficiency balancing technology.
High-performance optical storage all-in-one: support load, battery, power grid or diesel generator, photovoltaic simultaneously.
Multi-capability of one machine: energy storage mode, solve the small power supply, and off-grid uninterrupted power supply, dynamic capacity expansion, peak cutting and valley filling optimization power mode.
The energy storage system is prefabricated in the factory to reduce the cost of on-site installation.
Maximize the use of green energy and save money on electricity bills.
| Common parameter | EnerCube-250KW516KWh-M | |
| Battery parameter | ||
| Cell type | LFP 280Ah | |
| Battery Pack configuration | 14.336KWh/1P16S | |
| Battery system configuration | (172KWh/1P192S) *3 | |
| Battery voltage range | 538~691V | |
| Temperature measurement quantity | 72*3 | |
| Charging/discharge ratio | ≤0.5C | |
| The depth of discharge | 90%DOD | |
| Cycles | >8000 | |
| Maximum battery system efficiency | ≥96% | |
| AC parameter | ||
| Rated AC power | 250KW | |
| Maximum AC power | 275KW | |
| Rated voltage | 400V (-20%~+15%) | |
| Rated current | 360A | |
| Rated frequency | 50/60Hz | |
| DC current component | <0.5%Ipn | |
| AC current distortion rate | <3% | |
| Power factor | -1~+1 | |
| Overload capacity | 110% long term | |
| Alternating current system | Three-phase four-wire + ground wire (3W+N+PE) | |
| Isolation transformer | Yes | |
| Common parameter | ||
| Battery outdoor cabinet | PCS outdoor cabinet | |
| Protection class | IP55 | IP54 |
| Fire protection system | Perfluorohexone + aerosol | -- |
| Operating temperature range | -30℃ to 55℃ | -30℃ to 55℃ |
| Cooling mode | Air conditioning cooling | Intelligent air cooling |
| Size WDH (mm) | (1200 * 1100 * 2350) *3 | 1500 * 1100 * 2350 |
| Weight (kg) | 2200*3 | 2000 |
| Communication mode | CAN, RS485 | RS485, TCP/IP |
| Display | Touch LCD display | Touch LCD display |
| Relative humidity | 5~95%RH, no condensation | 5~95%RH, no condensation |
| Highest altitude | 4500m (> 3000 Derating required) | 4500m (> 3000 Derating required) |
| Noise | <70dB | <70dB |
