Equipped with high-quality LFP energy storage-specific cells, boasting a cycle life of over 8000 times to ensure long-term reliable operation.
IP55 protection rating, fully meeting the environmental adaptability requirements of outdoor application scenarios.
Adopt cabinet partition safety isolation + pack-level safety warning + fire prevention system to ensure comprehensive system safety and control.
Utilize air conditioner air cooling technology to maintain each battery cell at an optimal temperature range, effectively ensuring battery performance and cycle life.
High-efficiency equalization BMS: single-series design + high-efficiency equalization technology, achieving 0 system parallel capacity loss and maximizing battery utilization efficiency.
Standardized design significantly reduces operation and maintenance (O&M) costs, while standardized production enables fast delivery and lower overall lifecycle costs.
Support infinite parallel connection, realizing elastic capacity expansion and fully modular maintenance of energy storage power stations; capable of supporting multi-scenario applications from kWh to MWh level.
| Model | EnerCube-143KWh |
| DC battery parameters | |
| Types of batteries | LFP 280Ah |
| Battery Pack Configuration | 14.336KWh/1P16S |
| Battery System Configuration | 143KWh/1P160S |
| Rated voltage | 512V |
| Battery voltage range | 448~576V |
| Number of temperature measurements | 60 |
| System parameters | |
| Maximum system efficiency | ≥94% |
| Charge/discharge ratio | ≤0.5C |
| The depth of discharge | 100%DOD |
| Cycles | >8000 |
| Communication interface | CAN/RS485/LAN |
| Protection grade | IP55 |
| Type of cooling | Air conditioning air cooling |
| Operating temperature | -35℃~+55℃ |
| Relative humidity | 5~95%RH, No condensation |
| Noise | <70dB |
| Altitude | <2000m |
| Size(WHD) | 120022801100mm |
| Fire fighting system | Aerosol + Pack-level immersion + Active warning |
| Weight | 1975kg |
