Select high-quality LFP cells dedicated for energy storage, with a cycle life of more than 8000 times.
IP55 protection rating to meet the requirements of outdoor applications.
Cabinet partition safety isolation + pack-level safety warning and fire prevention to ensure system safety and control.
Air conditioner air cooling is adopted to maintain each cell of the battery pack at an appropriate temperature, ensuring battery performance and cycle life.
Efficient equalization BMS: single series design + efficient equalization technology, with 0 system parallel capacity loss.
Standardized design for lower O&M costs, standardized production for fast delivery, and lower overall lifecycle costs.
Infinite parallel connection enables elastic expansion and fully modular maintenance of the energy storage power station, supporting multi-scenario applications from kWh to MWh level.
| Model | EnerCube-129KWh |
| DC battery parameters | |
| Types of batteries | LFP 280Ah |
| Battery Pack Configuration | 14.336KWh/1P16S |
| Battery System Configuration | 129KWh/1P144S |
| Rated voltage | 460.8V |
| Battery voltage range | 403.2~518.4V |
| Number of temperature measurements | 54 |
| System parameters | |
| Maximum system efficiency | ≥94% |
| Charge/discharge ratio | ≤0.5C |
| The depth of discharge | 100%DOD |
| Cycles | >8000 |
| Communication interface | CAN/RS485/LAN |
| Protection grade | IP55 |
| Type of cooling | Air conditioning air cooling |
| Operating temperature | -35℃~+55℃ |
| Relative humidity | 5~95%RH, No condensation |
| Noise | <70dB |
| Altitude | <2000m |
| Size(WHD) | 120022801100mm |
| Fire fighting system | Aerosol + Pack-level immersion + Active warning |
| Weight | 1850kg |
Residential
Industrial and Commercial
Data Center
Railway
Telecom Base Station
Motive Power
Others
